P200 Construction Positioning Harness with Back and Side D-Rings
The 3M™ Protecta® P200 1161206 is a comfort construction positioning harness with a Medium/Large harness body and an X-Large body belt. Its fixed dorsal D-ring supports the primary fall-arrest connection, while the two side D-rings and padded belt support approved work-positioning applications.
This configuration uses a pass-through chest buckle, tongue-buckle leg straps, durable polyester webbing, comfort padding, an Easy-Link web adapter, and auto-resetting lanyard keepers. A lanyard, self-retracting lifeline, anchorage connector, and other system components are sold separately unless the selected offer expressly states otherwise.
Quick Buying Details
Key Features
- Fixed dorsal D-ring
- Two positioning D-rings
- Padded construction body belt
- Pass-through chest buckle
- Tongue-buckle leg straps
- Auto-resetting lanyard keepers
- Easy-Link web adapter
- Impact indicators and protected labels
Common Work Applications
- Construction positioning
- Structural work at height
- Industrial maintenance
- Utility maintenance
- General fall-arrest programs
- Tasks requiring a padded tool belt
Confirm the Exact P200 Configuration Before Ordering
Part 1161206 is not a universal S/M/L/XL family SKU. 3M identifies it as the 1161205 Medium/Large harness fitted with an X-Large belt. Match the harness size, belt size, buckle style, D-ring layout, manufacturer part number, and physical product label to the worker and written fall-protection plan.
The 3M catalog states that P200 harnesses support workers up to 420 lb, including clothing and tools. The fit range and the capacity of the complete anchorage, connector, lanyard or SRL, and rescue system must also be suitable for the user. Follow the lowest rated component and the current 3M user instructions.
Fall Protection Selection and Inspection
A full-body harness is one component of a complete personal fall-protection system. A qualified or competent person must select the anchorage, connector, energy absorber or SRL, clearance, attachment point, and rescue plan for the task and workplace.
Use the dorsal D-ring only as directed for fall arrest. Side/hip D-rings are for approved positioning applications and are not the primary fall-arrest attachment. Inspect the harness before each use, remove it from service after an impact event or failed inspection, and follow the current 3M instructions, product label, ANSI/ASSP Z359.11 requirements, and applicable OSHA rules.
FAQ - 3M Protecta P200 Harness 1161206
What size is the 3M Protecta 1161206 harness?
3M identifies 1161206 as a Medium/Large Comfort Construction harness fitted with an X-Large body belt. It is not four interchangeable S/M/L/XL variants under one manufacturer part number.
What are the back and side D-rings used for?
The dorsal back D-ring is the primary fall-arrest attachment point when the complete system is designed for that use. The two side/hip D-rings support approved work positioning. Follow the current 3M instructions and the written fall-protection plan for each attachment element.
Does this P200 harness include a lanyard or self-retracting lifeline?
No. This offer is for the harness unless the selected listing expressly states otherwise. The lanyard or SRL, anchorage connector, and other system components must be selected separately for the task, worker capacity, fall clearance, and compatibility requirements.
What is the worker capacity of the P200 harness?
The 3M Protecta catalog states a worker capacity of up to 420 lb, including clothing and tools. The complete system must support the user, and the lowest rated component controls. Verify the physical label and current instructions before use.
Which buckles are used on model 1161206?
The official 3M selection guide identifies a pass-through chest buckle and tongue-buckle leg straps for this Comfort Construction configuration.
Is the P200 1161206 suitable for confined-space retrieval?
Do not select this harness for retrieval based only on its back and side D-rings. Confined-space retrieval configurations require the attachment elements and complete rescue system specified by the manufacturer and the site rescue plan.
Does this harness meet ANSI and OSHA requirements?
3M lists its P200 full-body harnesses as meeting ANSI Z359.11 and OSHA requirements. Compliance depends on selecting, fitting, inspecting, and using the complete system according to the product label, current 3M instructions, the written program, and applicable regulations.
When should this harness be removed from service?
Remove it from service after a fall-arrest event, a failed inspection, missing or illegible labels, damaged webbing or hardware, deployed impact indicators, or any condition identified in the current 3M user instructions. Do not return it to use unless 3M procedures permit it.
